Data Link

S BAND TDMA DATA LINK

This compact, power-efficient S-Band TDMA MESH (ADHOC) Data Link supports both point-to-point and point-to-multipoint communication, ideal for establishing versatile network connections. Its small form factor and low power consumption make it suitable for mini, midi, and tactical UAV platforms. Incorporating an SDR modem, the system utilizes advanced modulation methods for enhanced performance and optimal spectrum usage. AES-256 encryption and spread spectrum techniques like FHSS and DSSS are available options. It also includes relay capabilities, enabling self-forming and self-healing mesh networks. Data rates up to 10 Mbps can be dynamically adjusted.

Key Benefits:

• Mission-critical capabilities including UAV swarm operations, tactical communication, convoy connectivity, and precise synchronization.
• Reliable connectivity under extreme conditions for sectors such as mining, oil and gas, agriculture, ports, and utilities.
• Autonomous, integrated, and optimized operational capabilities ensuring increased productivity and dependable command and control.

Key Specifications:

• High efficiency and lightweight design
• Compact size and easy integration
• Point-to-multipoint and mesh network support
• Up to 10 Mbps adjustable data rate
• Swarm operation capability
• Dynamic routing and relay functions
• Accurate time synchronization
• RF range determination capabilities

L BAND TDMA DATA LINK

Compact, power-efficient L Band TDMA MESH (ADHOC) Data Link supports versatile point-to-point and point-to-multipoint communications, suitable for a variety of UAV platforms, including mini, midi, and tactical UAVs. Featuring an SDR modem, it employs advanced modulation methods for superior performance and optimal use of spectrum. Optional AES-256 encryption and spread spectrum techniques such as FHSS and DSSS are available. The data link offers mesh networking capabilities, including relay functions, with manual or automatic data rate adjustments up to 10 Mbps based on application requirements. It supports dynamic network participation with automated joining, leaving, and time slot adjustments to ensure optimized bandwidth.thernet or serial interfaces.

Key Benefits:

• Mission-critical applications including UAV swarm operations, reliable synchronization, position tracking, convoy communications, and enhanced communication range.
• Robust connectivity suitable for extreme conditions in mining, oil and gas, agriculture, ports, utilities, and other demanding environments.
• Autonomous and integrated operations for improved productivity and reliable command and control.

Key Specifications::

• High efficiency, lightweight, compact, and easy integration
• Point-to-multipoint and automatic networking capability
• Up to 10 Mbps adjustable data rates
• Comprehensive mesh networking and swarm capability
• Dynamic route management and relay mechanisms
• Self-forming and self-healing network structures
• Total throughput capacity of 10 Mbps

LS BAND UAV DATA LINK 2W/5W/10W

The LS BAND UAV 2W Data Link is a compact, high-performance digital datalink designed specifically for UAV Intelligence, Surveillance, and Reconnaissance (ISR) operations. It supports multiplexing of video and telemetry data within the airborne module, with corresponding demultiplexing on the ground module for operator interface visualization. Capable of full duplex communication, the system operates in both L and S Bands at data rates up to 10 Mbps, with higher data rates optionally available for specialized requirements. Supported modulation methods include CPFSK, MSK, and PSK. Its small form factor and minimal power consumption enable seamless integration into mini, midi, and tactical UAV platforms. The ground module shares similar compact dimensions, making it ideal for deployment in mobile ground terminals.

Key Specifications:

• High Efficiency
• Data Rates up to 10 Mbps
• Low Power Consumption
• Lightweight and Compact
• Easy Integration
• Integrated Low Noise Amplifier (LNA) and Power Amplifier (PA)

C BAND UAV DATA LINK

The C Band UAV Data Link is a compact, efficient, and high-performance digital communication system tailored for UAV Intelligence, Surveillance, and Reconnaissance (ISR) missions. It effectively multiplexes video and telemetry data in the airborne unit, with corresponding demultiplexing at the ground station for operator interface visualization. Its small size and superior efficiency make this data link ideal for Tactical, Medium Altitude Long Endurance (MALE), and High Altitude Long Endurance (HALE) UAV platforms. It features transparent Ethernet (10/100 Base-T) and RS 232/422/485 data interfaces, secured by AES 256 encryption. An optional H.264 video encoder is available, and advanced error correction methods, including Reed Solomon (RS), Convolutional, and LDPC encoding, significantly enhance receiver sensitivity. The system operates full-duplex across lower and upper C Band frequencies, supporting data rates up to 10 Mbps, with optional higher data rates for specialized requirements. Available modulation types include CPFSK, MSK, and PSK.

Key Specifications:

• Full Duplex Communication
• High Efficiency
• Data Rates up to 10 Mbps
• Low Power Consumption
• Easy Integration
• Lightweight and Compact

AUTO TRACKING ANTENNA SYSTEM

The Ground Terminal with Autotracking Antenna System provides reliable long-range communication capabilities, particularly for airborne platforms and UAVs. Designed for seamless integration with data links, it supports both mobile and stationary applications. This terminal features a user-friendly interface and a rapidly deployable structure, ideal for quick field setup and ease of use. Utilizing GPS-based autotracking, it facilitates full-duplex and half-duplex bidirectional communication with ranges exceeding 200 km.

Key Features:

• Long-range communication over 200 km
• Full-duplex and half-duplex communication options
• GPS autotracking capability
• Quick deployment and user-friendly operation
• Suitable for mobile and fixed platform installations
